AC/DC High Voltage Power Supplies

Digital Controlled AC/DC High Voltage Power Supplies

HPS Series

HPS devices are digital controlled AC driven high voltage power supplies with high power density at best output charactereistics. The processor controlled supplies can flexibly be adapted to any kind of application by configuring many options.

PWM controlled output parameters, small ripple and noise and stored energy, up to 93% efficiency and almost loss free switching of semiconductors makes HPS devices the most advanced AC/dC HV power supply for industrial and reserach applications.

Key Features:

best control characteristics
multiple interface options
capacitor charger option (optional CLD)
ultrafast ARC management (optional ARC/ARCpro)
very low ripple and noise, very low EMI
parallel operation for power increase
integrated filament current supply (optional FCS) technical details see FPS

Application Areas:

Research and Education
Development Labs
Industrial Applications

Device types and series / HPS Series

Model	HPS 1.5kW - 10kW	HPS 300W/800W	HPS 350W
Channel	1	1	1
Vnom	800V-100kV	1kV - 30kV	1kV - 70kV
Ripple & Noise	1· 10-3 · Vnom - 9· 10-3 · Vnom	1· 10-4 · Vnom - 5· 10-4 · Vnom	2· 10-3 · Vnom
HV connector	LEMO, GES, SHV	SHV, LEMO	GES, Special connector
Interfaces	USB, RS232, LAN, CAN, IEEE488, AIO, SPS	USB, RS232, LAN, CAN, IEEE488, AIO	USB, RS232, LAN, CAN, IEEE488
Options	CUSTOM, EOA, FCS, FP, VLN, WR4	ARC, CLD	ARC, CLD
Datasheet Download	Datasheet HPS-Series (pdf)

*) Model overview of each series is shown in the tables below.

>> Quote request

Models HPS Series (1.5kW - 10kW) 2U. 3U and 4U

Model	_Vnom	I_nom	P_nom/ch	ripple &noise	HV con.	HU/19"
HPx 10 158 152	1kV	1.5A	1.5kW	3V	SHV	2U
HPx 20 757 152	2kV	750mA	1.5kW	6V	SHV	2U
HPx 30 507 152	3kV	500mA	1.5kW	9V	SHV	2U
HPx 40 387 152	4kV	380mA	1.5kW	12V	SHV	2U
HPx 80 197 152	8kV	190mA	1.5kW	24V	LEMO	2U
HPx 100 157 152	10kV	150mA	1.5kW	30V	LEMO	2U
HPx 120 137 152	12kV	125mA	1.5kW	36V	GES	2U
HPx 150 107 152	15kV	100mA	1.5kW	45V	GES	2U
HPx 200 756 152	20kV	75mA	1.5kW	60V	GES	2U
HPx 300 506 152	30kV	50mA	1.5kW	90V	GES	3U
HPx 400 386 152	40kV	38mA	1.5kW	120V	GES	3U
HPx 500 306 152	50kV	30mA	1.5kW	150V	GES	3U
HPx 600 256 152	60kV	25mA	1.5kW	180V	GES	3U
HPx 800 206 152	80kV	20mA	1.5kW	240V	GES	4U
HPx 1000 156 152	100kV	15mA	1.5kW	300V	GES	4U
HPx 10 308 302	1kV	3A	3kW	5V	SHV	2U
HPx 20 158 302	2kV	1.5A	3kW	10V	SHV	2U
HPx 30 108 302	3kV	1A	3kW	15V	SHV	2U
HPx 40 757 302	4kV	0.75A	3kW	20V	SHV	2U
HPx 60 507 302	6kV	500mA	3kW	30V	LEMO	2U
HPx 80 387 302	8kV	375mA	3kW	40V	LEMO	2U
HPx 120 257 302	12kV	250mA	3kW	60V	GES	2U
HPx 150 207 302	15kV	200mA	3kW	75V	GES	2U
HPx 200 157 302	20kV	150mA	3kW	100V	GES	2U
HPx 300 107 302	30kV	100mA	3kW	150V	GES	3U
HPx 400 756 302	40kV	75mA	3kW	200V	GES	3U
HPx 500 606 302	50kV	60mA	3kW	250V	GES	3U
HPx 600 506 302	60kV	50mA	3kW	300V	GES	3U
HPx 800 386 302	80kV	38mA	3kW	400V	GES	4U
HPx 1000 306 302	100kV	30mA	3kW	500V	GES	4U
HPx 10 608 602	1kV	6A	6kW	9V	GES	4U
HPx 20 308 602	2kV	3A	6kW	18V	LEMO	4U
HPx 30 208 602	3kV	2A	6kW	27V	LEMO	4U
HPx 40 158 602	4kV	1.5A	6kW	36V	LEMO	4U
HPx 50 128 602	5kV	1.2A	6kW	45V	LEMO	4U
HPx 60 108 602	6kV	1A	6kW	54V	LEMO	4U
HPx 80 757 602	8kV	750mA	6kW	72V	LEMO	4U
HPx 100 607 602	10kV	600mA	6kW	90V	LEMO	4U
HPx 200 307 602	20kV	300mA	6kW	180V	GES	4U
HPx 10 109 103	1kV	10A	10kW	9V	GES	4U
HPx 20 508 103	2kV	5A	10kW	18V	LEMO	4U
HPx 30 348 103	3kV	3.4A	10kW	27V	LEMO	4U
HPx 40 258 103	4kV	2.5A	10kW	36V	LEMO	4U
HPx 50 208 103	5kV	2A	10kW	45V	LEMO	4U
HPx 60 178 103	6kV	1.7A	10kW	54V	LEMO	4U
HPx 80 138 103	8kV	1.25A	10kW	72V	LEMO	4U
HPx 100 108 103	10kV	1A	10kW	90V	LEMO	4U
HPx 200 507 103	20kV	0.5A	10kW	180V	GES	4U

All models: 1 channel, 19"rackmount, polarity positive or negative.

Models HPS Series (300W/800W) 1U

Model	_Vnom	I_nom	P_nom/ch	ripple &noise	HV con.	HU/19"
HPx 10 307 301	1kV	300mA	300W	0.1V	SHV	1U
HPx 20 157 301	2kV	150mA	300W	0.2V	SHV	1U
HPx 30 107 301	3kV	100mA	300W	0.3V	SHV	1U
HPx 40 756 301	4kV	75mA	300W	0.4V	SHV	1U
HPx 60 506 301	6kV	50mA	300W	0.6V	SHV	1U
HPx 80 356 301	8kV	35mA	300W	0.8V	SHV	1U
HPx 120 256 301	12kV	25mA	300W	6V	LEMO	1U
HPx 150 206 301	15kV	20mA	300W	7.5V	LEMO	1U
HPx 200 156 301	20kV	15mA	300W	10V	LEMO	1U
HPx 300 106 301	30kV	10mA	300W	15V	LEMO	1U
HPx 10 807 801	1kV	800mA	800W	0.1V	SHV	1U
HPx 20 407 801	2kV	400mA	800W	0.2V	SHV	1U
HPx 30 257 801	3kV	250mA	800W	0.3V	SHV	1U
HPx 40 207 801	4kV	200mA	800W	0.4V	SHV	1U
HPx 60 137 801	6kV	130mA	800W	0.6V	SHV	1U
HPx 80 107 801	8kV	100mA	800W	0.8V	SHV	1U
HPx 120 656 801	12kV	65mA	800W	6V	LEMO	1U
HPx 150 506 801	15kV	50mA	800W	7.5V	LEMO	1U

All models: 1 channel, 19"rackmount, polarity positive (p) or negative (n).

>> Quote request

Models HPS Series (350W) Desktop

Model	_Vnom	I_nom	P_nom/ch	ripple &noise	HV con.	Case
HPx 10 357 351	1kV	350mA	350W	2V	GES	DT
HPx 20 177 351	2kV	175mA	350W	4V	GES	DT
HPx 30 127 351	3kV	120mA	350W	6V	GES	DT
HPx 50 706 351	5kV	70mA	350W	10V	GES	DT
HPx 80 456 351	8kV	45mA	350W	16V	GES	DT
HPx 100 356 351	10kV	35mA	350W	20V	GES	DT
HPx 150 236 351	15kV	23mA	350W	30V	GES	DT
HPx 200 186 351	20kV	18mA	350W	40V	GES	DT
HPx 300 126 351	30kV	12mA	350W	60V	GES	DT
HPx 400 905 351	40kV	9mA	350W	80V	spec. con.	DT
HPx 500 705 351	50kV	7mA	350W	100V	spec. con.	DT
HPx 600 605 351	60kV	6mA	350W	120V	spec. con.	DT
HPx 700 505 351	70kV	5mA	350W	140V	spec. con.	DT

Spalte 2

All models: Desktop case, 1 channel, polarity positive (p) or negative (n).
